Kategorie: Garmin GPSMAP Ersatzteile

Overview

This collection covers replacement LCD touch screens and screen glass for the Garmin GPSMAP series of marine chartplotters and fishfinders, spanning compact 4-inch handheld-style units up to large 24-inch helm displays. Every part is an original Garmin component, tested before shipping, graded 90-100% new condition, and backed by a 3-month warranty.

We've supplied Garmin repair parts for 9 years and can help identify hard-to-find or discontinued parts not listed here — contact us if you don't see your exact model.

What's Covered

• 79 GPSMAP models across the 4xx, 5xx, 6xx, 7xx, 9xx, 10xx, 12xx, and large-format 7000/8000-series product lines, including standard, "xs", and "xsv" (sonar-integrated) variants
• Screen sizes from 4" to 24"
• Two repair categories:
  • Screen — complete LCD/touch display assemblies
  • Screen Glass — outer glass/digitizer only, for units where the LCD itself is undamaged

Condition & Warranty

• Condition: Original Garmin parts, 90-100% new
• Testing: Every unit is tested before shipping
• Warranty: 3 months

How to Find the Right Part

Garmin frequently reuses similar model numbers across different variants (standard vs. "xs" vs. "xsv", "Plus" vs. "Touch" vs. non-Plus). Before ordering:

1. Confirm the exact model number printed on your unit's housing — don't rely on screen size alone.
2. Check whether your unit is the standard, "xs", or "xsv" (sonar-integrated) variant, as these frequently use different display assemblies.
3. Decide whether you need a complete screen assembly or just the outer glass — if your touch input and image are both intact but the outer glass is cracked, Screen Glass may be the lower-cost option.
4. If you're unsure which part matches your unit, check the individual product page for detailed compatibility notes, or contact us before ordering.

Full Model Index

Common Reasons to Replace a GPSMAP Screen

• Cracked or shattered outer glass
• Unresponsive or partially unresponsive touchscreen
• Dead pixels, discoloration, or no image
• Water intrusion damage (common on flybridge/helm-mounted units)
• Display flickering or backlight failure

Installation

Most GPSMAP units use a marine-rated, weather-sealed housing. Installation involves opening the sealed enclosure and reconnecting internal display/touch connectors — professional installation is recommended to preserve water resistance, especially on larger network-integrated displays. See each product's page for model-specific installation notes.

FAQ

Q: How do I know which screen fits my exact GPSMAP model?
A: Match the exact model number on your unit's housing (not just the screen size) to the corresponding product listing. Standard, "xs", and "xsv" variants of the same number are often not interchangeable.

Q: What's the difference between "Screen" and "Screen Glass" parts?
A: "Screen" is a complete LCD/touchscreen assembly. "Screen Glass" is the outer glass/digitizer layer only — a lower-cost option if your display panel itself is still functioning.

Q: Are these original Garmin parts?
A: Yes — all parts in this collection are original Garmin components, graded 90-100% new condition, and tested before shipping.

Q: Is there a warranty?
A: Yes, all parts in this collection carry a 3-month warranty.

Q: What if my exact model isn't listed?
A: We've supplied Garmin repair parts for 9 years and can often help source hard-to-find or discontinued models — contact us directly.
