1. Product Overview

This is a genuine OEM pull LCD touch screen display, removed from an original Garmin DriveSmart 76 unit. It is available in two variants — with the outer frame/bezel included, or as a screen-only assembly — and neither includes adhesive. It is intended for users replacing a cracked, unresponsive, or otherwise damaged display on their DriveSmart 76 unit.

2. Compatibility

Compatible:

• Garmin DriveSmart 76

Not confirmed:

• Garmin DriveSmart 66 (6" display, lower resolution, different hardware)
• Garmin DriveSmart 86 (8" display)
• Garmin DriveSmart 65 / DriveSmart 61 (also use a 6.95" display size but different resolution/hardware generation — do not assume interchangeability without confirmation)
• Other Drive or DriveSmart series models

Garmin's DriveSmart lineup includes several models with overlapping display sizes but different resolutions and internal hardware. The DriveSmart 76 uses a 6.95" diagonal display (1024 x 600 resolution). Confirm the exact model printed on the back of your device before ordering, since similarly sized screens are not automatically interchangeable across DriveSmart generations.

3. Common Replacement Scenarios

This part is typically needed when the original display shows:

• Cracked or shattered glass
• Unresponsive or partially unresponsive touchscreen
• Dead pixels or display artifacts
• No image / black screen despite the unit powering on
• Discoloration, flickering, or abnormal display output

4. Key Features

• Genuine OEM pull — sourced from an original Garmin DriveSmart 76 unit, not aftermarket
• Combined LCD panel and capacitive touch digitizer layer
• Available in two configurations: with frame/bezel, or screen-only
• Does not include adhesive in either configuration; adhesive should be sourced separately for reassembly
• Matches original display specification: 6.95" diagonal (6.0"W x 3.5"H active area), 1024 x 600 resolution, multi-touch glass HD TFT with backlight

5. Specifications

6. Installation Notes

Replacing this component involves opening the device housing and disconnecting the internal flex cable that links the screen to the mainboard. Since adhesive is not included in either variant, reassembly requires separately sourced adhesive strips to properly seat the screen (and frame, if that variant is selected) against the housing. This repair involves flex connectors and precise alignment, so professional installation or prior repair experience is recommended to avoid damaging the connector or surrounding components.

7. What Is Included

• 1x Garmin DriveSmart 76 LCD touch screen display (OEM pull)
• Frame/bezel: choose "With Frame" or "Screen Only" variant
• Adhesive: not included in either variant

8. Buying Checklist

• Confirm your device is the Garmin DriveSmart 76 (not DriveSmart 66, 65, 61, or 86)
• Decide whether you need the "With Frame" or "Screen Only" variant based on the condition of your original frame
• Note that adhesive is not included — source separately for reassembly
• Compare the connector position and flex cable orientation with your original screen before ordering
• Confirm whether professional installation is required for your comfort level

Package Include

• Repair parts are shown in the picture.

Product Inspection

• Display Screen Check
• Cable Connection Check
• Frame Waterproof Test
• Contact Oxidation Inspection
